Product Model

NetSure V200 Retrofit

Enables eSure rectifiers, NetSure rectifiers, and legacy PCUs to be used side-by-side in existing large power plants, improving system efficiency and permitting expansion.

Get Manual

Benefits

Extend the life of legacy systems and improve efficiency to save cost
Keep your plant up and running during installation and maintenance with hot swappable modules
Compatible with or without original rectifiers in same system

Features

Plugs into existing rectifier slots without any electrical or mechanical adjustments to existing shelf or system
NetSure reliability improves mean time between failure (MTBF)
Enhanced controller features including single point adjustment and remote access via Ethernet
Enables connection to remote monitoring via SNMP and web

NetSure V200 Retrofit
Product Overview
Power Capacity
11 kW
Current Capacity
220 A
System Type
Retrofit
Input
Input Voltage, Nominal
208 VAC to 480 VAC, three phase
Input Voltage, Operational
260-530 VAC
Output
Output Voltage, Nominal
48 VDC
Output Voltage, Operational
42.0 VDC to 58.0 VDC
Output Capacity
3 (3,500 W rectifiers)
Peak Efficiency
96%
Environmetal & Standard Compliance
Control and Monitoring
MCA controller
Operating Temperature
0 to +50 °C (operating), -40 to +167 °F (storage)
Safety Compliance
UL/EN/IEC 60950-2000 CE
EMC Compliance
Compliant

*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
