Specifications
Technical Specifications
MMD96E, 24.9kW
- Product Specifications
- Total Nominal Capacity kBtuh [kW]
- 84.9 [24.9]
- Net Sensible Capacity kBtuh [kW]
- 84.9 [24.9]
- Nominal Airflow [CFM]
- 3750
- Total Capacity
- 92.7 [27.2]
- Heat Rejection Medium
- Air
- Controls and Monitoring
- iCOM CMS Monitoring & Management System
- Physical Characteristics
- Weight
- 665
- Weight
- 302
- Height
- 26 1/2
- Height
- 673
- Width
- 69 1/2
- Width
- 1765
- Depth
- 54 1/8
- Depth
- 1375
- Liebert Mini-Mate2 8 Ton User Manual SL-10533
- Vertiv™ Liebert® Mini-Mate2 1 & 1.5 Ton Installer User Guide SL-10530
- Vertiv™ Liebert® Mini-Mate2 2 and 3 Ton User Manual SL-10531
- Vertiv™ Liebert® Mini-Mate2 5 Ton User Manual SL-10532
- Vertiv™ Liebert® IS-UNITY-DP User Manual for Liebert Mini-Mate2 and Liebert DataMate
- Vertiv™ Liebert® iCOM CMS Quick Installation Guide - Mini-Mate2
- Liebert® Mini-Mate2 2 and 3 Ton System Design Catalog SL-10535
- Liebert Mini-Mate2 8 Ton System Design Catalog SL-10537
- Vertiv™ Liebert® Mini-Mate2 System Design Catalog SL-10525
- Liebert® Mini-Mate2 5 Ton System Design Catalog SL-10536
- Liebert® Mini-Mate2 1 & 1.5 Ton Guide Specifications SL-10525GS
- Liebert® Mini-Mate2 2 & 3 Ton Guide Specifications SL-10535GS
- Liebert Mini-Mate2 5 Ton Guide Specifications (SL-10536GS)
- Liebert Mini-Mate2 8 Ton Guide Specifications (SL-10537GS)
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
MMD96E, 24.9kW
The Liebert Mini-Mate is designed for data center cooling, humidity control and air filtration of small areas, such as computer, control and equipment rooms. The system installs above a dropped ceiling, is easy to install and service and requires only front access for maintenance. The Liebert Mini-Mate is available in nominal cooling capacities from 3.5 to 28 kW (1 to 8 tons), with air, water, glycol and chilled water models available in 50 and 60 Hz. All chilled water systems are self-contained units. Air, water and glycol cooled models are available in split-system configurations.
Warranty : One Year Limited Warranty Against Defects in Material and Workmanship
