Product Model

VP4UU0A1

Unit Level Monitored Universal Rack Power Distribution Unit (UPDU) VP4UU0A1 with input power monitoring. It has 42 Combination C13/C19 outlets, a universal input, and a max power capacity of 11kW. The UPDU supports common AC power configurations ranging from 16A-48A and 120V-415V in single or three phase. Select the Facility Side Cable (FSC - sold separately) to define the input power configuration.

Find Sales Contact Get Brochure Get Manual

Best Suited For:

Banking
Financial and Insurance
Data Center/Colocation/Hosting
Education
Government
Healthcare
Power/Gas Transmission and Distribution

Warranty: Vertiv™ Geist™ UPDUs come with a standard three-year warranty that is automatically extended to five years, if the product is registered within 120 days of purchase.

Product Model

VP4UU0A1

Find Sales Contact Get Brochure Get Manual

Best Suited For:

Banking
Financial and Insurance
Data Center/Colocation/Hosting
Education
Government
Healthcare
Power/Gas Transmission and Distribution

Warranty: Vertiv™ Geist™ UPDUs come with a standard three-year warranty that is automatically extended to five years, if the product is registered within 120 days of purchase.

Benefits

The Universal Input enables users to utilize a single Universal PDU model with various input power configurations to simplify inventory management and enable rapid deployments worldwide.

Increase or decrease Universal PDU power capacity by changing the Facility Side Cable to adapt to fluctuating equipment power needs.

Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime.

The Combination OutletC13/C19 provides 2-in-1 receptacle versatility as each outlet functions as both an IEC C13 and C19.

Simplify the rack PDU buying process and accommodate ever-changing rack power requirements with the flexibility to connect C14 and C20 plugs in the same outlet with the Combination Outlet C13/C19.

Simplify cable management with the Combination Outlet C13/C19 with the ability to connect equipment to the closest available receptacle.

Easily identify circuits with color-coded P-Lock tabs and streamline circuit and phase balancing.

High retention outlets reduce the risk of costly downtime from accidental disconnections of the power cord.

Environmental monitoring capabilities ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.

Upgrade your hot-swappable monitoring device on the fly to leverage new technologies and accommodate changing business needs without having to replace entire power strips.

Gather comprehensive power data at the palm of your hand with the use of the Vertiv™ VLC mobile app.

Every unit is 100% tested for reliability and functionality to ensure units function as designed.

North American units are UL listed in accordance with common data center and insurance provider requirements.

Standard three-year warranty, upgraded to five years with product registration.

Features

The universal power input can mate to any geographically specific Facility Side Cable and is designed to operate with variable power input configurations (defined by the connected cable).

The Pivoting Connector adjusts from 0 to 90 degrees to assist with power cable routing.

Every outlet on the rPDU is a Combination Outlet C13/C19.

Color-coded P-Lock compatible tabs for use with P-Lock cords.

Hot-Swappable and upgradeable monitoring device.

Local and remote power monitoring with accuracy of +/- 1% (ANSI & IEC Standards).

VLC (Visible Light Communication).

Environmental monitoring with the addition of optional sensors.

High Temperature Grade 60°C for high temperature environments.

Simple and quick installation in all standard racks or cabinets with included mounting brackets.

TAA compliant.

The LCD touchscreen of the IMD-5M auto-orients for both vertical and horizontal units.

Enhanced with Secure Boot, the Hardware key and Firmware key must match to boot up.

When connected with another rPDU via a redundant power cable, the IMD-5M remains powered when the rPDU loses power.

Vertiv™ Geist™ UPDUs are available in 11kW and 22kW max power load capacities in both vertical and horizontal form factors with various receptacle combinations and monitoring options. To view the full list of available models visit the rPDU Finder.

Print Download Email

VP4UU0A1

Power Description

Frequency: 50/60Hz

Operational Conditions

Operating Temperature: 60C

Physical Characteristics

Weight: 22 lbs

Height: 72 in

Width: 2 in

Depth: 2.25 in
