NetSure 5000 Series DC Power System
DC Power systems designed for full flexibility with a wide variety of configurations for various wireless access sites - on-grid, off-grid and bad grid - as well as for fixed network applications.
Famiglia di prodotti
NetSure 5000 Series DC Power System
DC Power systems designed for full flexibility with a wide variety of configurations for various wireless access sites - on-grid, off-grid and bad grid - as well as for fixed network applications.
Particolarmente adatto per:
- Broadcast and Entertainment
- Data CenterColocationHosting
- Military Defense Aerospace and Missile
- Telecom
- Government
Specifiche
|
NetSure 5100 Hybrid DC Power System
|
||||||||
|---|---|---|---|---|---|---|---|---|
| 6 kW - 24 kW | 125 A - 500 A | 48 VDC / 24 VDC | Single phase: 220 VAC to 250 VAC | Subrack, Cabinet or Hardtop | 330 mm or 367 mm | 7 - 25 kg | ||
| Vedi maggiori informazioni sul prodotto | ||||||||
|
NetSure 5100 DC Power System
|
||||||||
| 6 kW - 24 kW | 125 A - 500 A | 48 VDC | Single phase: 220 VAC to 250 VAC | Subrack, Cabinet or Hardtop | - | - | 330 mm or 367 mm | 7 - 25 kg |
| Vedi maggiori informazioni sul prodotto |
Vantaggi
Optimized total cost of ownership with high efficiency eSure rectifiers
OpEx savings with environmentally durable model (up to +65 °C without derating)
Optimized battery capacity with up to two load disconnect levels (LVD)
Reduced grid-dependency with solar/hybrid capability
Significant energy savings, even at low loads with ECO Mode
Possible to detect backup problems early with automatic battery testing
Caratteristiche
96.2% efficient eSure rectifiers
Wide operating temperature range from -40 °C to +80 °C, up to +65 °C without derating
Solar/hybrid capability
Up to three load disconnect levels (LVD)
Remote access – monitoring through web browsers, TCP/IP & SNMP as standard
Battery management
