CR040RC, Chilled Water, 40kW
Quick Access
Specifications
Technical Specifications
CR040RC, Chilled Water, 40kW
- Product Specifications
- Total Nominal Capacity kBtuh [kW]
- 119.4 [40.0]
- Net Sensible Capacity kBtuh [kW]*
- 146.4 [42.9]
- Nominal Airflow [CFM]
- 3325
- Total Capacity
- 159.9 [46.9]
- Airflow Direction
- Adjustable baffles
- Heat Rejection Medium
- Chilled Water
- Capacity Modulation
- Variable Speed EC Fans
- Controls & Monitoring
- Liebert iCOM Unit Controls
- Physical Characteristics
- Weight
- 727.52 (330)
- Height
- 78.74 (2000)
- Width
- 23.62 (600)
- Depth
- 46.26 (1175)
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
