Product

Liebert® TW420 and THW420 Environmental Sensors

These temperature and humidity sensors provide accurate sensing of room temperature and humidity, transmitting the data via 4-20 mA output signal to the Liebert® Universal Monitor.

Get Manual
Best Suited For:
  • Retail and Wholesale
Warranty: One Year Limited Warranty Against Defects in Material and Workmanship.

Benefits

Means of bridging the data center connectivity gap by the Liebert SiteScan monitoring software
Helps to avoid potentially hazardous problems
Easy to install
Transmission over long distances without degradation of the 4-20 mA signal

Features

TW420 sensor monitors temperature;
THW420 sensor monitors temperature and humidity
Communicate to the Liebert® Universal Monitor
Provides 4-20mA signals
Monitored temperature range of 45°F to 96°F (7°C to 35°C)
Monitored humdity range of 0 to 100% relative humidity

Liebert® TW420 and THW420 Environmental Sensors
Technical Specifications
Product Line
Sensor
Mounting
Wall mount
Power Input
24 VDC
Ports
4-20 mA
Operating Environment
45 to 96 degrees F
Environmental Sensors
Temperature and Humidity
Weight
1 lb
Weight
0.45 kg
Height
4.5 in
Height
114 mm
Width
2.86 in
Width
73 mm
Depth
1.06 in
Depth
27 mm
