Product Model

Cybex™ SCM185DPH Secure Desktop Matrix

The Vertiv™ Cybex™ Secure Desktop Matrix allows users to securely interact with multiple computers and observe two active computers simultaneously. Designed for Common Criteria Protection Profile for Peripheral Sharing Device (PSD) v.4.0, the Cybex Secure Desktop Matrix is ideal for environments where monitoring and managing of multiple computers, covering various degrees of secure data is required.

Find Sales Contact Get Manual
Login to Save for Later
Best Suited For:
  • Government
  • Healthcare
Warranty: 3 Year Full Coverage Factory Warranty - Optional Extended Warranty Available

Benefits

View information on two isolated computers simultaneously. Block unauthorized USB devices while allowing secure switching of smart card and biometric devices between computers Universal video connectors to support DP, HDMI, and DVI-D Vertiv™ patented keyboard lock status indication Active intrusion detection and tamper-evident holographic labels prevent hardware from being compromised

Features

Designed for Common Criteria Protection Profile for Peripheral Sharing Device (PSD) v.4.0 Secure KVM switching allows for instantaneous interaction between two computers from different security classifications Cursor Navigation Switching (CNS) seamlessly transitions keyboard and mouse control between computers when pressing the left CTRL key and moving the cursor across screen borders Native video supports up to UHD 4K at 60 Hz Unidirectional data flow of keyboard, mouse, video, and audio

Cybex™ SCM185DPH Secure Desktop Matrix
Power Description
Power Supply(s)
1 x internal, 45W Max
Interfaces/Ports
Network Interface(s)
100-240V AC
Operational Conditions
Operating Temperature
32° to 104° F (0° to 40° C)
Humidity
0-80% RH, non-condensing
Storage Temperature
-4° to 140° F (-20° to 60° C)
Physical Characteristics
Weight
5.4 lbs
Weight
2.5 kgs
Height
1.7 in
Height
43 mm
Width
17.3 in
Width
439 mm
Depth
7.3 in
Depth
185 mm
Miscellaneous
Agency Approvals
FCC class A, CE, TUV US, TUV Canada, RCM, VCCI

*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
