Productgroep

Liebert® Trinergy™ Cube UPS, 150 kW-3.4 MW

Liebert® Trinergy™ Cube is the new generation of Trinergy UPS delivering unsurpassed performance to enterprise data centers. Ready to evolve with growing business demands, it offers the highest level of power availability as well as reduced TCO, minimum energy consumption and CO2 emissions.

Brochure aanvragen
Meest geschikt voor:
  • Banking Financial and Insurance
  • Data CenterColocationHosting
  • Telecom
  • Healthcare
  • Manufacturing

Liebert® Trinergy™ Cube boasts unparalleled features including an average operational efficiency of 98.5%, maximum efficiency up to 99.5% and power density per core running up to 400 kW. Trinergy Cube is the only unit in the market which allows for hot scalability up to 3,4 MW in a single UPS and up to 27 MW in parallel. Trinergy Cube intelligently adapts load power supply to respond to the environment conditions of the installation site. The system’s I/O Box and cores are rated to operate continuously up to 55°C and provide increased performances down to 20°C.

Voordelen

Types of modularity of the Liebert Trinergy Cube high-efficiency UPS
Uptime Enhancement
24/7 remote diagnostics
Efficient data tracking

Flexibility
Adapts to physical space constraints
Ideal for all sites: any geographical location and new or existing buildings
Allows more free space for IT equipment

Adaptive Power Rating
Adapts power supplied to the load to respond to the environment conditions of the installation site
Optimized TCO
Significant electrical infrastructure and space savings

Kenmerken

Main benefits and advantages of 1 Trinergy Cube online UPS unit
Availability
Predictive maintenance
Event analysis, waveform capturing and harmonic spectrum analyses
Data logging
LIFE™ remote diagnostic and preventive monitoring service embedded in the UPS

Capacity & Installation Flexibility
Configurable in various layouts
Simplified cable routing with unlimited input / output power connection availability
Increased energy density
Single unit configuration up to 3,4 MW

Smart Capacity
I/O Box and cores rated to operate continuously up to 55°C and capable of providing increased performance down to 20°C
Maximum input current of the UPS adjustable to meet specific protection rating requirements.

Efficiency
Average operating efficiency of 98.5%
Adoption of a three-level NPC2 topology for both rectifier and inverter

* Voor modelspecifieke downloads dient u naar de modelspecifieke productpagina te gaan door de naam van het model te selecteren in bovenstaande specificatietabel.
