Vertiv™ Avocent® IPSL Serial Device
The Vertiv™ Avocent® IPSL is an innovative serial IP solution that scales from edge to enterprise and increases productivity by simplifying remote access and troubleshooting of IT devices.
- Banking, Financial and Insurance
- Broadcast and Entertainment
- Data Center/Colocation/Hosting
- Education
- Healthcare
- Government
- Manufacturing
- Retail and Wholesale
- Telecom
- Transportation
Benefits
- Reduces cost through reduction/elimination of on-site visits.
- Reduces time to provision new equipment.
- Improves visibility into remote locations.
- Increases productivity with remote serial access to IT devices.
Features
- Small Form Factor: Portable size for easy deployment at edge locations.
- IP Addressable: Reachable from anywhere on the network to enable remote management of serial devices.
- Security: Secure Boot with hardware root of trust for tamper proof firmware, TLS1.3, AES256 bit encryption for all communication to and from the IP serial dongle.
- Virtual Media: Mount virtual drives remotely to transfer files such as firmware upgrades or other configuration files.
- Serial: Manage up to four serial targets simultaneously with SSH serial redirection
- HTML5: HTML5 Web based user interface for simplified management.
Specifications
The Vertiv™ Avocent® DSView™ Solution is built upon a secure common architecture which seamlessly integrate and scale to create an open yet resilient IT management platform – from Enterprise to Edge configurations. Avocent® DSView™ Solution provides the highest performance and agility, security, and enables automation, management, monitoring and control of all your devices like no other solution in the market. The Vertiv™ Avocent® MP1000 Management Platform allows users to manage service processors, virtual machines, IP KVM modules and remote access appliances. It also provides centralized firmware update capability to IT devices and limits security risks. The Vertiv™ Avocent® RM1048 Rack Manager uses a single IP to access devices, reduces power and cabling costs with PoE and can offer over 100+ user sessions without more hardware. The Vertiv™ Avocent® IPUHD 4K IP KVM offers remote 4K KVM with fast and precise mouse synchronization and end to end encryption of all traffic. It offers HDMI, DP, MiniDP adapters along with native USB-C for plug and play connectivity. The Vertiv™ Avocent® IPIQ IP KVM solution scales from edge to enterprise and increases productivity by simplifying remote access and troubleshooting of IT devices with enhanced video resolution.
- Product Overview
- Type
- Digital Infrastructure
- Ports
- 1 x 1G (PoE), 2 x RJ45, 2 x USB A, 1 x Power port
- Power
- 1 x Power port
- Connectors
- n/a
- Video Resolution
- n/a
- Graphic Mode
- Humidity
- 5% to 80% Non-Condensing
- Power Description
- Network Interfaces
- 1 x 1G (PoE)
- Serial Ports
- 2 x RJ45, 2 x USB Type A
- Interfaces/Ports
- USB Ports
- USB Micro B
- Operating Temperature
- 0 to 60°C
- Operational Conditions
- Agency Approvals
- Please reference Data Sheet for Agency Approvals
- Physical Characteristics
- Depth
- 5.8 in
