Vertiv Knürr Rack Locking Systems
This Vertiv Knürr Rack Locking Systems is a mechanical locking solution providing access control for your data center racks and cabinets. It ensures the security of your enclosures through centralized management software. On-site technicians receive visual alerts and alarms from the multi-colored LEDs on the swinghandles to show authorized and unauthorized access attempts
- Banking, Financial and Insurance
- Data Center/Colocation/Hosting
- Healthcare
- Power Generation
- Retail and Wholesale
- Telecom
- Transportation
- Broadcast and Entertainment
- Education
- Government
- Fire/Alarm/Security
Specifications
- Two-part hardware design Swing handle and control unit. - Visualization Multicolored status LED - Optional Reader For 125 kHz transponders (HID 26 bit system), alternatively 13.56 MHz (MIFARE) Reader - Power supply 12 V ± 10 % (DC) via low voltage socket - Standby current (system ready) 40 mA (DC) - Max. current consumption (with connector tightening) 440 mA (DC) - Managed version with Door contact - Temperature range -20°C – +70°C
Managed or unmanaged electromagnetic locking systems with or without remote management, monitoring and log functionality. LED clearly signal the lock status and they help to identify rack doors within a Datacenter. Manage versions can store up to 2000 access rights information. Managed version use transponder cards and/or Pin Codes as Identification. Customized solutions can be offered with interfaces to Mobil Phone Security Apps, Biometric ID devices or other 3rd party access control systems.
Benefits
Features
Operating mode 100 % ED
Installation position Vertical
Connection type Screw clamps, 2.5mm2
