Vertiv™ CoolLoop Thermal Wall - 500 kW, CA80
The Vertiv™ CoolLoop Thermal Wall is a turnkey cooling solution delivering 350 to 500 kW, designed to elevate the performance of chilled water air handling units for slab floor installations. Positioned on the gallery side, it supports a wide range of IT loads, from traditional air-cooled systems to advanced hybrid cooling for AI and HPC environments. It helps cloud, hyperscale, and colocation data centers meet key goals such as increasing rack density, reducing operating costs, and accelerating deployment. Additionally, it addresses critical business and technical needs including space optimization, temperature control, operational reliability, enhanced efficiency, and simplified installation.
Saved This Product to Your Dashboard
You just saved this product to your dashboard to view at a later time. You can easily remove the item from your dashboard when you no longer wish to have it saved.
Please login or create an account to save this for later
- Data Center/Colocation/Hosting
Vertiv™ CoolLoop Thermal Wall - 500 kW, CA80
The Vertiv™ CoolLoop Thermal Wall is a turnkey cooling solution delivering 350 to 500 kW, designed to elevate the performance of chilled water air handling units for slab floor installations. Positioned on the gallery side, it supports a wide range of IT loads, from traditional air-cooled systems to advanced hybrid cooling for AI and HPC environments. It helps cloud, hyperscale, and colocation data centers meet key goals such as increasing rack density, reducing operating costs, and accelerating deployment. Additionally, it addresses critical business and technical needs including space optimization, temperature control, operational reliability, enhanced efficiency, and simplified installation.
- Data Center/Colocation/Hosting
Benefits
- DENSITY AT SCALE: The unit delivers 350 to 500 kW of cooling capacity, supporting higher cooling density per footprint in large-scale IT environments.
- REDUCED LOGISTICS: Modular sections lower shipping costs while enabling fast commissioning and easy installation.
- HIGHER COOLING CAPACITY: The high-performance EC fans increase cooling capacity without increasing the unit footprint.
- GROWTH-READY DESIGN: This cooling solution supports a data center’s evolving requirements through its extended operating ranges, scalable fan options, and custom coils.
- RAPID ON-SITE DEPLOYMENT: It provides fast commissioning and a range of optional features to align with your business needs.
Features
- HIGH-EFFICIENCY EC FANS: ErP‑compliant, latest generation EC fans help boost airflow and cooling performance while reducing energy consumption.
- ENHANCED COIL PERFORMANCE: Multiple enhanced coils increase heat transfer capacity to support higher cooling output and improved thermal performance.
- LOWER PRESSURE AIRFLOW: The unit design reduces internal aerodynamic resistance to minimize air pressure drop and lower overall power consumption.
- PRECISION WATERFLOW CONTROL: The pressure independent control valve maintains a constant flow rate to ensure stable water distribution and optimized system efficiency.
- FLANGED PIPING CONNECTIONS: Flange connections simplify installation and servicing by enabling secure, consistent, and leak‑resistant hydronic tie‑ins.
- FACTORY-INTEGRATED CONTROLS: Vertiv™ Liebert® iCOM™ controls are factory installed and tested to enable faster start‑up, coordinated operation, and optimized cooling performance.
- TOUCHSCREEN USER INTERFACE: The touchscreen display provides intuitive local control for quick configuration, monitoring, and diagnostics.
- POWER CONTINUITY DESIGN: The dual power supply with control power continuity keeps the control system operational during power events to maintain reliable unit performance.
- SEISMIC-RATED CONSTRUCTION: IBC seismic certification ensures the unit includes structural bracing that enables safe installation and operation in seismic zones.
Specifications
Designed for large‑capacity environments, the Vertiv™ CoolLoop Thermal Wall scales up to 500 kW to support larger, non‑raised floor data center building blocks. It integrates into chilled water systems and accommodates a wide range of IT loads, from traditional air‑cooled deployments to higher‑density AI applications.
- Technical Specifications
- Total Nominal Capacity kBtuh [kW]
- 500
- Net Sensible Capacity kBtuh [kW]
- 1706
- Nominal Airflow [CFM]
- 80047
- Physical Characteristics
- Height
- 144 inches
- Height
- 3670 mm
- Width
- 155 inches
- Width
- 3960 mm
- Depth
- 58 inches
- Depth
- 1480 mm
