Product Family

Vertiv XTE PTS Series

Vertiv XTE PTS Series provides main service disconnect, AC surge protection, AC distribution and generator connection in a single environmentally protected enclosure geared toward remote telecom installations.

Get Brochure
Warranty: One-Year Limited Warranty Against Defects in Material and Workmanship

Model Specifications Overview
Vertiv XTE ATS, Outdoor
Enclosure   Off-White   200A or 400A Outdoor ATS   43.2; 68.00   21.4; 25.5   9.0, 6.0   90-110
Vertiv XTE ATS, Indoor
Enclosure   Off-white   200A indoor ATS, 42 position, MOV surge protection   65.0in; 68.0 in   20.0 in;25.5 in   5.75 in; 6.0 in   110 lbs
Vertiv XTE PTS, Power Protection Cabinets
Enclosure   Off-white   PPC Series power transfer pedestals   39.00-59.00 in   20.00-30.00 in   10.00-20.00 in   75-150 lbs
Vertiv XTE PTS, Power Transfer Switches
Enclosure   Off-white   100A or 200A PTS, AC load center, generator   60 in   9.2 in   22 in

Benefits

Application flexibility with numerous configuration options
All in one solution saves space and minimizes deployment time
Mounting options include remote placement and enclosure integration

Features

UL891 listed enclosure and system, UL type 3R rainproof
Equipment/ground isolation provides positive grounding for all components
Dual polarity active power indicator light
Three-point locking system accessed using a 216-type tool, with padlock provisions
Aluminum or galvanized construction with stainless steel hardware for durability, light weight and low maintenance
Multistage powder finishing process meets EPA standards and provides a tough corrosion-resistant finish

*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
